Texas Instruments TMS570LC4357 User Manual

www.ti.com SCI/LIN Control Registers
1713
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
Serial Communication Interface (SCI)/ Local Interconnect Network (LIN)
Module
29.7.28 LIN Transmit Buffer 0 Register (LINTD0)
Figure 29-57 and Table 29-45 illustrate this register.
Figure 29-57. LIN Transmit Buffer 0 Register (LINTD0) (offset = 74h)
31 24 23 16
TD0 TD1
R/W-0 R/W-0
15 8 7 0
TD2 TD3
R/W-0 R/W-0
LEGEND: R/W = Read/Write; -n = value after reset
Table 29-45. LIN Transmit Buffer 0 Register (LINTD0) Field Descriptions
Bit Field Value Description
31-24 TD0 0-FFh 8-Bit transmit buffer 0. Byte 0 to be transmitted is written into this register and then copied to
SCITXSHF for transmission. Once byte 0 is written in TD0 buffer, transmission will be initiated.
Note: TD<x-1> is equivalent to data byte <x> of the LIN frame.
23-16 TD1 0-FFh 8-Bit transmit buffer 1. Byte 1 to be transmitted is written into this register and then copied to
SCITXSHF for transmission.
15-8 TD2 0-FFh 8-Bit transmit buffer 2. Byte 2 to be transmitted is written into this register and then copied to
SCITXSHF for transmission.
7-0 TD3 0-FFh 8-Bit transmit buffer 3. Byte 3 to be transmitted is written into this register and then copied to
SCITXSHF for transmission.
29.7.29 LIN Transmit Buffer 1 Register (LINTD1)
Figure 29-58 and Table 29-46 illustrate this register.
Figure 29-58. LIN Transmit Buffer 1 Register (LINTD1) (offset = 78h)
31 24 23 16
TD4 TD5
R/W-0 R/W-0
15 8 7 0
TD6 TD7
R/W-0 R/W-0
LEGEND: R/W = Read/Write; -n = value after reset
Table 29-46. LIN Transmit Buffer 1 Register (LINTD1) Field Descriptions
Bit Field Value Description
31-24 TD4 0-FFh 8-Bit transmit buffer 4. Byte 4 to be transmitted is written into this register and then copied to
SCITXSHF for transmission.
Note: TD<x-1> is equivalent to data byte <x> of the LIN frame.
23-16 TD5 0-FFh 8-Bit transmit buffer 5. Byte 5 to be transmitted is written into this register and then copied to
SCITXSHF for transmission.
15-8 TD6 0-FFh 8-Bit transmit buffer 6. Byte 6 to be transmitted is written into this register and then copied to
SCITXSHF for transmission.
7-0 TD7 0-FFh 8-Bit transmit buffer 7. Byte 7 to be transmitted is written into this register and then copied to
SCITXSHF for transmission.
