www.ti.com
System and Peripheral Control Registers
167
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
Architecture
2.5.1.16 GCLK1, HCLK, VCLK, and VCLK2 Source Register (GHVSRC)
The GHVSRC register, shown in Figure 2-23 and described in Table 2-35, controls the clock source
configuration for the GCLK1, HCLK, VCLK and VCLK2 clock domains.
Figure 2-23. GCLK1, HCLK, VCLK, and VCLK2 Source Register (GHVSRC) (offset = 48h)
31 28 27 24 23 20 19 16
Reserved GHVWAKE Reserved HVLPM
R-0 R/WP-0 R-0 R/WP-0
15 4 3 0
Reserved GHVSRC
R-0 R/WP-0
LEGEND: R = Read only; R/W = Read/Write; WP = Write in privileged mode only; -n = value after reset
Table 2-35. GCLK1, HCLK, VCLK, and VCLK2 Source Register (GHVSRC) Field Descriptions
Bit Field Value Description
31-28 Reserved 0 Reads return 0. Writes have no effect.
27-24 GHVWAKE GCLK1, HCLK, VCLK source on wakeup.
0 Clock source0 is the source for GCLK1, HCLK, VCLK on wakeup.
1h Clock source1 is the source for GCLK1, HCLK, VCLK on wakeup.
2h Clock source2 is the source for GCLK1, HCLK, VCLK on wakeup.
3h Clock source3 is the source for GCLK1, HCLK, VCLK on wakeup.
4h Clock source4 is the source for GCLK1, HCLK, VCLK on wakeup.
5h Clock source5 is the source for GCLK1, HCLK, VCLK on wakeup.
6h Clock source6 is the source for GCLK1, HCLK, VCLK on wakeup.
7h Clock source7 is the source for GCLK1, HCLK, VCLK on wakeup.
8h-Fh Reserved
23-20 Reserved 0 Reads return 0. Writes have no effect.
19-16 HVLPM HCLK, VCLK, VCLK2 source on wakeup when GCLK1 is turned off.
0 Clock source0 is the source for HCLK, VCLK, VCLK2 on wakeup.
1h Clock source1 is the source for HCLK, VCLK, VCLK2 on wakeup.
2h Clock source2 is the source for HCLK, VCLK, VCLK2 on wakeup.
3h Clock source3 is the source for HCLK, VCLK, VCLK2 on wakeup.
4h Clock source4 is the source for HCLK, VCLK, VCLK2 on wakeup.
5h Clock source5 is the source for HCLK, VCLK, VCLK2 on wakeup.
6h Clock source6 is the source for HCLK, VCLK, VCLK2 on wakeup.
7h Clock source7 is the source for HCLK, VCLK, VCLK2 on wakeup.
8h-Fh Reserved
15-4 Reserved 0 Reads return 0. Writes have no effect.
3-0 GHVSRC GCLK1, HCLK, VCLK, VCLK2 current source.
Note: The GHVSRC[3-0] bits are updated with the HVLPM[3-0] setting when GCLK1 is
turned off, and are updated with the GHVWAKE[3-0] setting on system wakeup.
0 Clock source0 is the source for GCLK1, HCLK, VCLK, VCLK2.
1h Clock source1 is the source for GCLK1, HCLK, VCLK, VCLK2.
2h Clock source2 is the source for GCLK1, HCLK, VCLK, VCLK2.
3h Clock source3 is the source for GCLK1, HCLK, VCLK, VCLK2.
4h Clock source4 is the source for GCLK1, HCLK, VCLK, VCLK2.
5h Clock source5 is the source for GCLK1, HCLK, VCLK, VCLK2.
6h Clock source6 is the source for GCLK1, HCLK, VCLK, VCLK2.
7h Clock source7 is the source for GCLK1, HCLK, VCLK, VCLK2.
8h-Fh Reserved
