2.5.1.20 Memory Self-Test Global Control Register (MSTGCR)
The MSTGCR register, shown in Figure 2-27 and described in Table 2-39, controls several aspects of the
PBIST (Programmable Built-In Self Test) memory controller.
Figure 2-27. Memory Self-Test Global Control Register (MSTGCR) (offset = 58h)
31 24 23 16
Reserved Reserved
R-0 R/WP-0
15 10 9 8 7 4 3 0
Reserved ROM_DIV Reserved MSTGENA
R-0 R/WP-0 R-0 R/WP-5h
LEGEND: R = Read only; R/W = Read/Write; WP = Write in privileged mode only; -n = value after reset
Table 2-39. Memory Self-Test Global Control Register (MSTGCR) Field Descriptions
Bit Field Value Description
31-24 Reserved 0 Reads return 0. Writes have no effect.
23-16 Reserved 0-1 Reads return 0 or 1 and depends on what is written in privileged mode. The functionality of
these bits are unavailable in this device.
15-10 Reserved 0 Reads return 0. Writes have no effect.
9-8 ROM_DIV Prescaler divider bits for ROM clock source.
0 ROM clock source is GCLK1 divided by 1. PBIST will reset for 16 VBUS cycles.
1h ROM clock source is GCLK1 divided by 2. PBIST will reset for 32 VBUS cycles.
2h ROM clock source is GCLK1 divided by 4. PBIST will reset for 64 VBUS cycles.
3h ROM clock source is GCLK1 divided by 8. PBIST will reset for 96 VBUS cycles.
7-4 Reserved 0 Reads return 0. Writes have no effect.
3-0 MSTGENA Memory self-test controller global enable key
Note: Enabling the MSTGENA key will generate a reset to the state machine of the
selected PBIST controller.
Ah Memory self-test controller is enabled.
Others Memory self-test controller is disabled.
Note: It is recommended that a value of Ah be used to disable the memory self-test
controller. This value will give maximum protection from a bit flip inducing event that
would inadvertently enable the controller.
