SCI Control Registers

www.ti.com

1734

SPNU563A–March 2018

Submit Documentation Feedback

Serial Communication Interface (SCI) Module

30.7.1 SCI Global Control Register 0 (SCIGCR0)

The SCIGCR0 register defines the module reset. Figure 30-8 and Table 30-4 illustrate this register.

Figure 30-8. SCI Global Control Register 0 (SCIGCR0) [offset = 00]

31 16

Reserved

R-0

15 1 0

Reserved RESET

R-0 R/WP-0

LEGEND: R/W = Read/Write; R = Read only; R/WP = Read/Write in privileged mode only; -n = value after reset

Table 30-4. SCI Global Control Register 0 (SCIGCR0) Fied Descriptions

Bit Field Value Description

31-1 Reserved 0 Reads return 0. Writes have no effect.

0 RESET This bit resets the SCI module.

0 SCI module is in reset.

1 SCI module is out of reset.

Note: Read/Write in privileged mode only.
