SCI Control Registers
www.ti.com
1762
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
Serial Communication Interface (SCI) Module
Table 30-32. Input/Output Error Enable Register (IODFTCTRL) Field Descriptions (continued)
Bit Field Value Description
18-16 TX SHIFT Transmit shift. These bits define the amount by which the value on TX pin is delayed so that
the value on the RX pin is asynchronous. This feature is not applicable to the start bit.
0 No delay occurs.
1h The value is delayed by 1 SCLK.
2h The value is delayed by 2 SCLK.
3h The value is delayed by 3 SCLK.
4h The value is delayed by 4 SCLK.
5h The value is delayed by 5 SCLK.
6h The value is delayed by 6 SCLK.
7h No delay occurs.
15-12 Reserved 0 Reads return 0. Writes have no effect.
11-8 IODFTENA IODFT enable key. Write access permitted in Privilege mode only.
Ah IODFT is enabled.
All Others IODFT is disabled.
7-2 Reserved 0 Reads return 0. Writes have no effect.
1 LPBENA Module loopback enable. Write access permitted in Privilege mode only.
Note: In analog loopback mode the complete communication path through the I/Os
can be tested, whereas in digital loopback mode the I/O buffers are excluded from
this path.
0 Digital loopback is enabled.
1 Analog loopback is enabled in module I/O DFT mode when IODFTENA = 1010.
0 RXPENA Module analog loopback through receive pin enable. Write access permitted in Privilege
mode only.
This bit defines whether the I/O buffers for the transmit or the receive pin are included in the
communication path (in analog loopback mode).
0 Analog loopback through the transmit pin is enabled.
1 Analog loopback through the receive pin is enabled.
