Output enable

Data out

Data in

Pull control disable

Pull select

Device pin

Pull control

logic

Input enable

Output enable

Data out

Data in

Pull control disable

Device pin

Pull control

logic

Input enable

www.ti.com

GPIO Functionality

1763

SPNU563A–March 2018

Submit Documentation Feedback

Serial Communication Interface (SCI) Module

30.8 GPIO Functionality

The following sections apply to all device pins that can be configured as functional or general-purpose I/O

pins.

30.8.1 GPIO Functionality

Figure 30-32 illustrates the GPIO functionality.

Figure 30-32. GPIO Functionality

30.8.2 Under Reset

The following apply if a device is under reset:

• Pull control. The reset pull control on the pins is enabled.

• Input buffer. The input buffer is enabled.

• Output buffer. The output buffer is disabled.
