I2C Control Registers
www.ti.com
1782
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
Inter-Integrated Circuit (I2C) Module
31.6.1 I2C Own Address Manager (I2COAR)
The 16-bit memory-mapped I2C own address register is used to specify its own address. Figure 31-13
and Table 31-4 describe this register.
Figure 31-13. I2C Own Address Manager Register (I2COAR) [offset = 00]
15 10 9 0
Reserved OA
R-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 31-4. I2C Own Address Manager Register (I2COAR) Field Descriptions
Bit Field Value Description
15-10 Reserved 0 Reads return 0. Writes have no effect.
9-0 OA 0-3FFh Own address
These bits reflect the bus address of the I2C module. When the expand address (XA) bit
I2CMDR.8 is set to 1, the I2C is in expand address mode (10-bit addressing mode). In either 7
or 10-bit address mode, all 10-bits are both readable and writable. Bits 7, 8, and 9 should only
be used in 10-bit address mode. Table 31-5 provides the correct modes for these bits. Note that
the user can program the I2C own address to any value as long as it does not conflict with
other components in the system.
Table 31-5. Correct Mode for OA Bits
Bits Used Mode Value of XA
OA.6:0 7 Bit Addressing 0
OA.9:0 10 Bit Addressing 1
