www.ti.com
I2C Control Registers
1781
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
Inter-Integrated Circuit (I2C) Module
31.6 I2C Control Registers
Table 31-3 provides a summary of the control registers. The upper word (upper 16 bits) of the registers all
read as 0s. Writes have no effect on these bits. The base address for the control registers is FFF7 D400h
for I2C1 and FFF7 D500h for I2C2.
Table 31-3. I2C Control Registers
Offset Acronym Register Description Section
00h I2COAR I2C Own Address Manager Section 31.6.1
04h I2CIMR I2C Interrupt Mask Register Section 31.6.2
08h I2CSTR I2C Status Register Section 31.6.3
0Ch I2CCKL I2C Clock Divider Low Register Section 31.6.4
10h I2CCKH I2C Clock Control High Register Section 31.6.5
14h I2CCNT I2C Data Count Register Section 31.6.6
18h I2CDRR I2C Data Receive Register Section 31.6.7
1Ch I2CSAR I2C Slave Address Register Section 31.6.8
20h I2CDXR I2C Data Transmit Register Section 31.6.9
24h I2CMDR I2C Mode Register Section 31.6.10
28h I2CIVR I2C Interrupt Vector Register Section 31.6.11
2Ch I2CEMDR I2C Extended Mode Register Section 31.6.12
30h I2CPSC I2C Prescale Register Section 31.6.13
34h I2CPID1 I2C Peripheral ID Register 1 Section 31.6.14
38h I2CPID2 I2C Peripheral ID Register 2 Section 31.6.15
3Ch I2CDMACR I2C DMA Control Register Section 31.6.16
48h I2CPFNC I2C Pin Function Register Section 31.6.17
4Ch I2CPDIR I2C Pin Direction Register Section 31.6.18
50h I2CDIN I2C Data Input Register Section 31.6.19
54h I2CDOUT I2C Data Output Register Section 31.6.20
58h I2CDSET I2C Data Set Register Section 31.6.21
5Ch I2CDCLR I2C Data Clear Register Section 31.6.22
60h I2CPDR I2C Pin Open Drain Register Section 31.6.23
64h I2CPDIS I2C Pull Disable Register Section 31.6.24
68h I2CPSEL I2C Pull Select Register Section 31.6.25
6Ch I2CSRS I2C Pins Slew Rate Select Register Section 31.6.26
