www.ti.com EMAC Control Module Registers
1855
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
EMAC/MDIO Module
32.3.1 EMAC Control Module Revision ID Register (REVID)
The EMAC control module revision ID register (REVID) is shown in Figure 32-15 and described in
Table 32-11.
Figure 32-15. EMAC Control Module Revision ID Register (REVID) (offset = 00h)
31 0
REV
R-4EC8 0100h
LEGEND: R = Read only; -n = value after reset
Table 32-11. EMAC Control Module Revision ID Register (REVID) Field Descriptions
Bit Field Value Description
31-0 REV Identifies the EMAC Control Module revision.
4EC8 0100h Current revision of the EMAC Control Module.
32.3.2 EMAC Control Module Software Reset Register (SOFTRESET)
The EMAC Control Module Software Reset Register (SOFTRESET) is shown in Figure 32-16 and
described in Table 32-12.
Figure 32-16. EMAC Control Module Software Reset Register (SOFTRESET) (offset = 04h)
31 16
Reserved
R-0
15 1 0
Reserved RESET
R-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 32-12. EMAC Control Module Software Reset Register (SOFTRESET)
Bit Field Value Description
31-1 Reserved 0 Reserved
0 RESET Software reset bit for the EMAC Control Module. Clears the interrupt status, control registers, and CPPI
Ram on the clock cycle following a write of 1.
0 No software reset.
1 Perform a software reset.
