EMAC Module Registers
www.ti.com
1892
SPNU563AMarch 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
EMAC/MDIO Module
32.5.13 Receive Interrupt Status (Unmasked) Register (RXINTSTATRAW)
The receive interrupt status (unmasked) register (RXINTSTATRAW) is shown in Figure 32-54 and
described in Table 32-52.
Figure 32-54. Receive Interrupt Status (Unmasked) Register (RXINTSTATRAW) (offset = A0h)
31 16
Reserved
R-0
15 14 13 12 11 10 9 8
RX7THRESH
PEND
RX6THRESH
PEND
RX5THRESH
PEND
RX4THRESH
PEND
RX3THRESH
PEND
RX2THRESH
PEND
RX1THRESH
PEND
RX0THRESH
PEND
R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0
7 6 5 4 3 2 1 0
RX7PEND RX6PEND RX5PEND RX4PEND RX3PEND RX2PEND RX1PEND RX0PEND
R-0 R-0 R-0 R-0 R-0 R-0 R-0 R-0
LEGEND: R = Read only; -n = value after reset
Table 32-52. Receive Interrupt Status (Unmasked) Register (RXINTSTATRAW) Field Descriptions
Bit Field Value Description
31-16 Reserved 0 Reserved
15 RX7THRESHPEND 0-1 RX7THRESHPEND raw interrupt read (before mask).
14 RX6THRESHPEND 0-1 RX6THRESHPEND raw interrupt read (before mask).
13 RX5THRESHPEND 0-1 RX5THRESHPEND raw interrupt read (before mask).
12 RX4THRESHPEND 0-1 RX4THRESHPEND raw interrupt read (before mask).
11 RX3THRESHPEND 0-1 RX3THRESHPEND raw interrupt read (before mask).
10 RX2THRESHPEND 0-1 RX2THRESHPEND raw interrupt read (before mask).
9 RX1THRESHPEND 0-1 RX1THRESHPEND raw interrupt read (before mask).
8 RX0THRESHPEND 0-1 RX0THRESHPEND raw interrupt read (before mask).
7 RX7PEND 0-1 RX7PEND raw interrupt read (before mask).
6 RX6PEND 0-1 RX6PEND raw interrupt read (before mask).
5 RX5PEND 0-1 RX5PEND raw interrupt read (before mask).
4 RX4PEND 0-1 RX4PEND raw interrupt read (before mask).
3 RX3PEND 0-1 RX3PEND raw interrupt read (before mask).
2 RX2PEND 0-1 RX2PEND raw interrupt read (before mask).
1 RX1PEND 0-1 RX1PEND raw interrupt read (before mask).
0 RX0PEND 0-1 RX0PEND raw interrupt read (before mask).
