www.ti.com
EMAC Module Registers
1895
SPNU563AMarch 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
EMAC/MDIO Module
32.5.16 Receive Interrupt Mask Clear Register (RXINTMASKCLEAR)
The receive interrupt mask clear register (RXINTMASKCLEAR) is shown in Figure 32-57 and described in
Table 32-55.
Figure 32-57. Receive Interrupt Mask Clear Register (RXINTMASKCLEAR) (offset = ACh)
31 16
Reserved
R-0
15 14 13 12 11 10 9 8
RX7THRESH
MASK
RX6THRESH
MASK
RX5THRESH
MASK
RX4THRESH
MASK
RX3THRESH
MASK
RX2THRESH
MASK
RX1THRESH
MASK
RX0THRESH
MASK
R/W1C-0 R/W1C-0 R/W1C-0 R/W1C-0 R/W1C-0 R/W1C-0 R/W1C-0 R/W1C-0
7 6 5 4 3 2 1 0
RX7MASK RX6MASK RX5MASK RX4MASK RX3MASK RX2MASK RX1MASK RX0MASK
R/W1C-0 R/W1C-0 R/W1C-0 R/W1C-0 R/W1C-0 R/W1C-0 R/W1C-0 R/W1C-0
LEGEND: R/W = Read/Write; R = Read only; W1C = Write 1 to clear (writing a 0 has no effect); -n = value after reset
Table 32-55. Receive Interrupt Mask Clear Register (RXINTMASKCLEAR) Field Descriptions
Bit Field Value Description
31-16 Reserved 0 Reserved
15 RX7THRESHMASK 0-1 Receive channel 7 threshold mask clear bit. Write 1 to disable interrupt; a write of 0 has no
effect.
14 RX6THRESHMASK 0-1 Receive channel 6 threshold mask clear bit. Write 1 to disable interrupt; a write of 0 has no
effect.
13 RX5THRESHMASK 0-1 Receive channel 5 threshold mask clear bit. Write 1 to disable interrupt; a write of 0 has no
effect.
12 RX4THRESHMASK 0-1 Receive channel 4 threshold mask clear bit. Write 1 to disable interrupt; a write of 0 has no
effect.
11 RX3THRESHMASK 0-1 Receive channel 3 threshold mask clear bit. Write 1 to disable interrupt; a write of 0 has no
effect.
10 RX2THRESHMASK 0-1 Receive channel 2 threshold mask clear bit. Write 1 to disable interrupt; a write of 0 has no
effect.
9 RX1THRESHMASK 0-1 Receive channel 1 threshold mask clear bit. Write 1 to disable interrupt; a write of 0 has no
effect.
8 RX0THRESHMASK 0-1 Receive channel 0 threshold mask clear bit. Write 1 to disable interrupt; a write of 0 has no
effect.
7 RX7MASK 0-1 Receive channel 7 mask clear bit. Write 1 to disable interrupt; a write of 0 has no effect.
6 RX6MASK 0-1 Receive channel 6 mask clear bit. Write 1 to disable interrupt; a write of 0 has no effect.
5 RX5MASK 0-1 Receive channel 5 mask clear bit. Write 1 to disable interrupt; a write of 0 has no effect.
4 RX4MASK 0-1 Receive channel 4 mask clear bit. Write 1 to disable interrupt; a write of 0 has no effect.
3 RX3MASK 0-1 Receive channel 3 mask clear bit. Write 1 to disable interrupt; a write of 0 has no effect.
2 RX2MASK 0-1 Receive channel 2 mask clear bit. Write 1 to disable interrupt; a write of 0 has no effect.
1 RX1MASK 0-1 Receive channel 1 mask clear bit. Write 1 to disable interrupt; a write of 0 has no effect.
0 RX0MASK 0-1 Receive channel 0 mask clear bit. Write 1 to disable interrupt; a write of 0 has no effect.
