EMAC Module Registers
www.ti.com
1896
SPNU563AMarch 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
EMAC/MDIO Module
32.5.17 MAC Interrupt Status (Unmasked) Register (MACINTSTATRAW)
The MAC interrupt status (unmasked) register (MACINTSTATRAW) is shown in Figure 32-58 and
described in Table 32-56.
Figure 32-58. MAC Interrupt Status (Unmasked) Register (MACINTSTATRAW) (offset = B0h)
31 16
Reserved
R-0
15 2 1 0
Reserved HOSTPEND STATPEND
R-0 R-0 R-0
LEGEND: R = Read only; -n = value after reset
Table 32-56. MAC Interrupt Status (Unmasked) Register (MACINTSTATRAW) Field Descriptions
Bit Field Value Description
31-2 Reserved 0 Reserved
1 HOSTPEND 0-1 Host pending interrupt (HOSTPEND); raw interrupt read (before mask).
0 STATPEND 0-1 Statistics pending interrupt (STATPEND); raw interrupt read (before mask).
32.5.18 MAC Interrupt Status (Masked) Register (MACINTSTATMASKED)
The MAC interrupt status (masked) register (MACINTSTATMASKED) is shown in Figure 32-59 and
described in Table 32-57.
Figure 32-59. MAC Interrupt Status (Masked) Register (MACINTSTATMASKED) (offset = B4h)
31 16
Reserved
R-0
15 2 1 0
Reserved HOSTPEND STATPEND
R-0 R-0 R-0
LEGEND: R = Read only; -n = value after reset
Table 32-57. MAC Interrupt Status (Masked) Register (MACINTSTATMASKED) Field Descriptions
Bit Field Value Description
31-2 Reserved 0 Reserved
1 HOSTPEND 0-1 Host pending interrupt (HOSTPEND); masked interrupt read.
0 STATPEND 0-1 Statistics pending interrupt (STATPEND); masked interrupt read.
