EMAC/MDIO Module
Table 32-69. MAC Status Register (MACSTATUS) Field Descriptions (continued)
Bit Field Value Description
15-12 RXERRCODE Receive host error code. These bits indicate that EMAC detected receive DMA related host errors.
The host should read this field after a host error interrupt (HOSTPEND) to determine the error. Host
error interrupts require hardware reset in order to recover.
0 No error.
1h Reserved
2h Ownership bit not set in SOP buffer.
3h Reserved
4h Zero buffer pointer.
5h-Fh Reserved
11 Reserved 0 Reserved
10-8 RXERRCH Receive host error channel. These bits indicate which receive channel the host error occurred on.
This field is cleared to 0 on a host read.
0 The host error occurred on receive channel 0.
1h The host error occurred on receive channel 1.
2h The host error occurred on receive channel 2.
3h The host error occurred on receive channel 3.
4h The host error occurred on receive channel 4.
5h The host error occurred on receive channel 5.
6h The host error occurred on receive channel 6.
7h The host error occurred on receive channel 7.
7-3 Reserved 0 Reserved
2 RXQOSACT Receive Quality of Service (QOS) active bit. When asserted, indicates that receive quality of service
is enabled and that at least one channel freebuffer count (RXnFREEBUFFER) is less than or equal
to the RXFILTERLOWTHRESH value.
0 Receive quality of service is disabled.
1 Receive quality of service is enabled.
1 RXFLOWACT Receive flow control active bit. When asserted, at least one channel freebuffer count
(RXnFREEBUFFER) is less than or equal to the channel's corresponding RXnFILTERTHRESH
value.
0 Receive flow control is inactive.
1 Receive flow control is active.
0 TXFLOWACT Transmit flow control active bit. When asserted, this bit indicates that the pause time period is being
observed for a received pause frame. No new transmissions will begin while this bit is asserted,
except for the transmission of pause frames. Any transmission in progress when this bit is asserted
will complete.
0 Transmit flow control is inactive.
1 Transmit flow control is active.
