EMAC Module Registers
www.ti.com
1906
SPNU563AMarch 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
EMAC/MDIO Module
32.5.30 MAC Status Register (MACSTATUS)
The MAC status register (MACSTATUS) is shown in Figure 32-71 and described in Table 32-69.
Figure 32-71. MAC Status Register (MACSTATUS) (offset = 164h)
31 30 24 23 20 19 18 16
IDLE Reserved TXERRCODE Rsvd TXERRCH
R-0 R-0 R-0 R-0 R-0
15 12 11 10 8
RXERRCODE Reserved RXERRCH
R-0 R-0 R-0
7 3 2 1 0
Reserved RXQOSACT RXFLOWACT TXFLOWACT
R-0 R-0 R-0 R-0
LEGEND: R = Read only; -n = value after reset
Table 32-69. MAC Status Register (MACSTATUS) Field Descriptions
Bit Field Value Description
31 IDLE EMAC idle bit. This bit is cleared to 0 at reset; one clock after reset, it goes to 1.
0 The EMAC is not idle.
1 The EMAC is in the idle state.
30-24 Reserved 0 Reserved
23-20 TXERRCODE Transmit host error code. These bits indicate that EMAC detected transmit DMA related host errors.
The host should read this field after a host error interrupt (HOSTPEND) to determine the error. Host
error interrupts require hardware reset in order to recover. A 0 packet length is an error, but it is not
detected.
0 No error.
1h SOP error; the buffer is the first buffer in a packet, but the SOP bit is not set in software.
2h Ownership bit not set in SOP buffer.
3h Zero next buffer descriptor pointer without EOP.
4h Zero buffer pointer.
5h Zero buffer length.
6h Packet length error (sum of buffers is less than packet length).
7h-Fh Reserved
19 Reserved 0 Reserved
18-16 TXERRCH Transmit host error channel. These bits indicate which transmit channel the host error occurred on.
This field is cleared to 0 on a host read.
0 The host error occurred on transmit channel 0.
1h The host error occurred on transmit channel 1.
2h The host error occurred on transmit channel 2.
3h The host error occurred on transmit channel 3.
4h The host error occurred on transmit channel 4.
5h The host error occurred on transmit channel 5.
6h The host error occurred on transmit channel 6.
7h The host error occurred on transmit channel 7.
