EMAC/MDIO Module
32.5.48 Transmit Channel Completion Pointer Registers (TX0CP-TX7CP)
The transmit channel 0-7 completion pointer register (TXnCP) is shown in Figure 32-89 and described in
Table 32-87.
Figure 32-89. Transmit Channel n Completion Pointer Register (TXnCP) (offset = 640h-65Ch)
31 0
TXnCP
R/W-x
LEGEND: R/W = Read/Write; -n = value after reset; -x = value is indeterminate after reset
Table 32-87. Transmit Channel n Completion Pointer Register (TXnCP) Field Descriptions
Bit Field Description
31-0 TXnCP Transmit channel n completion pointer register is written by the host with the buffer descriptor address for the last
buffer processed by the host during interrupt processing. The EMAC uses the value written to determine if the
interrupt should be deasserted.
32.5.49 Receive Channel Completion Pointer Registers (RX0CP-RX7CP)
The receive channel 0-7 completion pointer register (RXnCP) is shown in Figure 32-90 and described in
Table 32-88.
Figure 32-90. Receive Channel n Completion Pointer Register (RXnCP) (offset = 660h-67Ch)
31 0
RXnCP
R/W-x
LEGEND: R/W = Read/Write; -n = value after reset; -x = value is indeterminate after reset
Table 32-88. Receive Channel n Completion Pointer Register (RXnCP) Field Descriptions
Bit Field Description
31-0 RXnCP Receive channel n completion pointer register is written by the host with the buffer descriptor address for the last
buffer processed by the host during interrupt processing. The EMAC uses the value written to determine if the
interrupt should be deasserted.
