Enhanced Pulse Width Modulator (ePWM) Module
35.4.6.5 Event-Trigger Clear Register (ETCLR)
Figure 35-89. Event-Trigger Clear Register (ETCLR) [offset = 3Ah]
15 8
Reserved
R-0
7 4 3 2 1 0
Reserved SOCB SOCA Reserved INT
R-0 R/W-0 R/W-0 R-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 35-49. Event-Trigger Clear Register (ETCLR) Field Descriptions
Bits Name Value Description
15-4 Reserved 0 Reserved
3 SOCB ePWM ADC Start-of-Conversion B (EPWMxSOCB) Flag Clear Bit.
0 Writing a 0 has no effect. Always reads back a 0.
1 Clears the ETFLG[SOCB] flag bit.
2 SOCA ePWM ADC Start-of-Conversion A (EPWMxSOCA) Flag Clear Bit.
0 Writing a 0 has no effect. Always reads back a 0.
1 Clears the ETFLG[SOCA] flag bit.
1 Reserved 0 Reserved
0 INT ePWM Interrupt (EPWMx_INT) Flag Clear Bit.
0 Writing a 0 has no effect. Always reads back a 0.
1 Clears the ETFLG[INT] flag bit and enable further interrupts pulses to be generated.
