www.ti.com
System and Peripheral Control Registers
211
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
Architecture
2.5.2.6 HCLK Control Register (HCLKCNTL)
This register is shown in Figure 2-64 and described in Table 2-77.
Figure 2-64. HCLK Control Register (HCLKCNTL) (offset = 54h)
31 16
Reserved
R-0
15 2 1 0
Reserved HCLKR
R-0 R/WP-0
LEGEND: R/W = Read/Write; R = Read only; WP = Write in privileged mode only; -n = value after reset
Table 2-77. HCLK Control Register (HCLKCNTL) Field Descriptions
Bit Field Value Description
31-2 Reserved 0 Reads return 0. Writes have no effect.
1-0 HCLKR HCLK divider value. The value of HCLKR bits determine the HCLK frequency as a ratio of GCLK1.
0 HCLK is equal to GCLK1 divide by 1.
1h HCLK is equal to GCLK1 divide by 2.
2h HCLK is equal to GCLK1 divide by 3.
3h HCLK is equal to GCLK1 divide by 4.
