Data Modification Module (DMM)
36.3.10 DMM Direct Data Mode Pointer Register (DMMDDMPT)
This register shows the pointer into the buffer programmed by DMMDDMDEST (Section 36.3.8) and
DMMDDMBL (Section 36.3.9).
Figure 36-16. DMM Direct Data Mode Pointer Register (DMMDDMPT) [offset = 24h]
31 16
Reserved
R-0
15 14 0
Rsvd POINTER
R-0 R-0
LEGEND: R = Read only; -n = value after reset
Table 36-16. DMM Direct Data Mode Pointer Register (DMMDDMPT) Field Descriptions
Bit Field Value Description
31-15 Reserved 0 Read returns 0. Writes have no effect.
14-0 POINTER These bits hold the pointer to the next entry to be written in the buffer. The pointer points to the byte
aligned address. If in 16-bit DDM mode, bit 0 will be 0. If in 32-bit DDM mode, bit 0 and 1 will be 0.
User and privilege mode (read): next data entry
Privilege mode (write): writes have no effect
36.3.11 DMM Direct Data Mode Interrupt Pointer Register (DMMINTPT)
This register can be programmed to hold a threshold to which the DMMDDMPT register (Section 36.3.10)
is compared. An interrupt can be generated when both match.
Figure 36-17. DMM Direct Data Mode Interrupt Pointer Register (DMMINTPT) [offset = 28h]
31 16
Reserved
R-0
15 14 0
Rsvd INTPT
R-0 R/WP-0
LEGEND: R/W = Read/Write; R = Read only; WP = Write in privilege mode only; -n = value after reset
Table 36-17. DMM Direct Data Mode Interrupt Pointer Register (DMMINTPT) Field Descriptions
Bit Field Value Description
31-15 Reserved 0 Read returns 0. Writes have no effect.
14-0 INTPT Interrupt Pointer. When the buffer pointer (Section 36.3.10) matches the programmed value in
DMMINTPT and the PROG_BUF interrupt (Section 36.3.2) is set, an interrupt is generated.
User and privilege mode (read): current interrupt threshold
Privilege mode (write): new interrupt threshold
