Control Registers and Control Packets

www.ti.com

726

SPNU563A–March 2018

Submit Documentation Feedback

Direct Memory Access Controller (DMA) Module

20.3.1.4 DMA Revision ID Register (DMAREVID)

Figure 20-22. DMA Revision ID Register (DMAREVID) [offset = 10h]

31 30 29 28 27 16

SCHEME Reserved FUNC

R-1 R-0 R-A0Dh

15 11 10 8 7 6 5 0

Reserved MAJOR Reserved MINOR

R-0 R-0 R-0 R-3h

LEGEND: R = Read only; -n = value after reset

Table 20-12. DMA Revision ID Register Description

Bit Field Value Description

31-30 SCHEME 1 Identification Scheme of REVID.

29-28 Reserved 0 Reads return 0. Writes have no effect.

27-16 FUNC A0Dh Indicates module family.

15-11 Reserved 0 Reserved

10-8 MAJOR 0 Major revision number.

7-6 Reserved 0 Reserved

5-0 MINOR 3h Minor revision number.
