www.ti.com
Control Registers and Control Packets
727
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
Direct Memory Access Controller (DMA) Module
20.3.1.5 HW Channel Enable Set and Status Register (HWCHENAS)
Figure 20-23. HW Channel Enable Set and Status Register (HWCHENAS) [offset = 14h]
31 0
HWCHENA[31:0]
R/WP-0
LEGEND: R/W = Read/Write; WP = Write in privilege mode only; -n = value after reset
Table 20-13. HW Channel Enable Set and Status Register (HWCHENAS) Field Descriptions
Bit Field Value Description
31-0 HWCHENA[n] Hardware channel enable bit. Bit 0 corresponds to channel 0, bit 1 corresponds to channel 1, and
so on. An active hardware DMA request cannot initiate a DMA transfer unless the corresponding
hardware enable bit is set.
The corresponding hardware enable bit is cleared automatically for the following conditions:
• At the end of a block transfer if the auto-initiation bit AIM (see CHCTRL) is not active.
• If a bus error is detected for an active channel.
Reading from HWCHENAS gives the status (enabled/disabled) of all channels.
0 The corresponding channel is disabled for hardware triggering.
1 The corresponding channel is enabled for hardware triggering.
20.3.1.6 HW Channel Enable Reset and Status Register (HWCHENAR)
Figure 20-24. HW Channel Enable Reset and Status Register (HWCHENAR) [offset = 1Ch]
31 0
HWCHDIS[31:0]
R/WP-0
LEGEND: R/W = Read/Write; WP = Write in privilege mode only; -n = value after reset
Table 20-14. HW Channel Enable Reset and Status Register (HWCHENAR) Field Descriptions
Bit Field Value Description
31-0 HWCHDIS[n] HW channel disable bit. Bit 0 corresponds to channel 0, bit 1 corresponds to channel 1, and so on.
0 Read: The corresponding channel is disabled for HW triggering.
Write: No effect.
1 Read: The corresponding channel is enabled for HW triggering.
Write: The corresponding channel is disabled.
