Control Registers and Control Packets
735
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
Direct Memory Access Controller (DMA) Module
20.3.1.17 DMA Request Assignment Register 4 (DREQASI4)
Figure 20-35. DMA Request Assignment Register 4 (DREQASI4) [offset = 64h]
31 30 29 24 23 22 21 16
Reserved CH16ASI Reserved CH17ASI
R-0 R/WP-10h R-0 R/WP-11h
15 14 13 8 7 6 5 0
Reserved CH18ASI Reserved CH19ASI
R-0 R/WP-12h R-0 R/WP-13h
LEGEND: R/W = Read/Write; R = Read only; WP = Write in privilege mode only; -n = value after reset
Table 20-25. DMA Request Assignment Register 4 (DREQASI4) Field Descriptions
Bit Field Value Description
31-30 Reserved 0 Reads return 0. Writes have no effect.
29-24 CH16ASI Channel 16 assignment. This bit field chooses the DMA request assignment for channel 16.
0 DMA request line 0 triggers channel 16.
: :
2Fh DMA request line 47 triggers channel 16.
30h-
3Fh
Reserved
23-22 Reserved 0 Reads return 0. Writes have no effect.
21-16 CH17ASI Channel 17 assignment. This bit field chooses the DMA request assignment for channel 17.
0 DMA request line 0 triggers channel 17.
: :
2Fh DMA request line 47 triggers channel 17.
30h-
3Fh
Reserved
15-14 Reserved 0 Reads return 0. Writes have no effect.
13-8 CH18ASI Channel 18 assignment. This bit field chooses the DMA request assignment for channel 18.
0 DMA request line 0 triggers channel 18.
: :
2Fh DMA request line 47 triggers channel 18.
30h-
3Fh
Reserved
7-6 Reserved 0 Reads return 0. Writes have no effect.
5-0 CH19ASI Channel 19 assignment. This bit field chooses the DMA request assignment for channel 19.
0 DMA request line 0 triggers channel 19.
: :
2Fh DMA request line 47 triggers channel 19.
30h-
3Fh
Reserved
