Control Registers and Control Packets
www.ti.com
746
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
Direct Memory Access Controller (DMA) Module
20.3.1.31 LFS Interrupt Enable Set Register (LFSINTENAS)
Figure 20-49. LFS Interrupt Enable Set Register (LFSINTENAS) [offset = ECh]
31 0
LFSINTENA[31:0]
R/WP-0
LEGEND: R/W = Read/Write; WP = Write in privilege mode only; -n = value after reset
Table 20-39. LFS Interrupt Enable Set Register (LFSINTENAS) Field Descriptions
Bit Field Value Description
31-0 LFSINTENA[n] Last frame started (LFS) interrupt enable. Bit 0 corresponds to channel 0, bit 1 corresponds to
channel 1, and so on.
0 Read: Corresponding LFS interrupt of a channel is disabled.
Write: No effect.
1 Read and write: LFS interrupt of the corresponding channel is disabled.
20.3.1.32 LFS Interrupt Enable Reset Register (LFSINTENAR)
Figure 20-50. LFS Interrupt Enable Reset Register (LFSINTENAR) [offset = F4h]
31 0
LFSINTDIS[31:0]
R/WP-0
LEGEND: R/W = Read/Write; WP = Write in privilege mode only; -n = value after reset
Table 20-40. LFS Interrupt Enable Reset Register (LFSINTENAR) Field Descriptions
Bit Field Value Description
31-0 LFSINTDIS[n] Last frame started (LFS) interrupt disable. Bit 0 corresponds to channel 0, bit 1 corresponds to
channel 1, and so on.
0 Read: LFS interrupt of the corresponding channel is disabled.
Write: No effect.
1 Read: LFS interrupt of the corresponding channel is enabled.
Write: LFS interrupt of the corresponding channel is disabled.
