Control Registers and Control Packets

761

SPNU563A–March 2018

Submit Documentation Feedback

Direct Memory Access Controller (DMA) Module

20.3.1.52 RAM Test Control Register (RTCTRL)

Figure 20-69. RAM Test Control Register (RTCTRL) [offset = 17Ch]

31 16

Reserved

R-0

15 1 0

Reserved RTC

R-0 R/WP-0

LEGEND: R/W = Read/Write; R = Read only; WP = Write in privilege mode only; -n = value after reset

Table 20-59. RAM Test Control Register (RTCTRL) Field Descriptions

Bit Field Value Description

31-1 Reserved 0 Reads return 0. Writes have no effect.

0 RTC RAM Test Control. Writing a 1 to this bit opens the write access to the reserved locations of control

packet RAM as defined in the memory-map.

Note: This bit should be cleared to 0 during normal operation.

0 RAM Test Control is disabled.

1 RAM Test Control is enabled.

Default Chapter2
