ADC Registers
www.ti.com
926
SPNU563A–March 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
Analog To Digital Converter (ADC) Module
22.3.38 ADC Group1 Results FIFO Register (ADG1BUFFER)
ADC Group1 Results FIFO Register (ADG1BUFFER) is shown in Figure 22-62 and Figure 22-63,
described in Table 22-44. As shown, the format of the data read from the ADG1BUFFER locations is
different based on whether the ADC module is configured to be a 12-bit or a 10-bit ADC module.
Figure 22-62. 12-bit ADC Group1 Results FIFO Register (ADG1BUFFER)
[offset = B0h-CFh]
31 30 21 20 16
G1_EMPTY Reserved G1_CHID
R-1 R-0 R-0
15 12 11 0
Reserved G1_DR
R-0 R-U
LEGEND: R = Read only; -n = value after reset; U = value after reset is unknown
Figure 22-63. 10-bit ADC Group1 Results' FIFO Register (ADG1BUFFER)
[offset = B0h-CFh]
31 16
Reserved
R-0
15 14 10 9 0
G1_EMPTY G1_CHID G1_DR
R-1 R-0 R-U
LEGEND: R = Read only; -n = value after reset; U = value after reset is unknown
Table 22-44. ADC Group1 Results FIFO Register (ADG1BUFFER) Field Descriptions
Field Value Description
Reserved 0 Reads return 0. Writes have no effect.
G1_EMPTY Group1 FIFO Empty. This bit is applicable only when the "read from FIFO" mode is used for reading the
Group1 conversion results.
Any operation mode read:
0 The data in the G1_DR field of this buffer is valid.
1 The data in the G1_DR field of this buffer is not valid and there are no valid data in the Group1 results
memory.
G1_CHID Group1 Channel Id. These bits are also applicable only when the "read from FIFO" mode is used for
reading the Group1 conversion results.
Any operation mode read:
0 The conversion result in the G1_DR field of this buffer is from the ADC input channel 0, or the channel id
mode is disabled in the Group1 mode control register (ADG1MODECR).
1h-1Fh The conversion result in the G1_DR field of this buffer is from the ADC input channel number denoted by
the G1_CHID field.
G1_DR Group1 Digital Conversion Result.
The Group1 results’ FIFO location is aliased eight times, so that any word-aligned read from the address
range B0h to CFh results in one conversion result to be read from the Group1 results’ memory. This allows
the ARM LDMIA instruction to read out up to 8 conversion results from the Group1 results’ memory with
just one instruction.
