1026 Keysight InfiniiVision 3000T X-Series Oscilloscopes Programmer's Guide

33 :TRIGger Commands

:TRIGger:EBURst Commands

The :TRIGger:EBURst:SOURce command is used to specify the source channel for

the Nth Edge Burst trigger. If an analog channel is selected as the source, the

:TRIGger:EDGE:LEVel command is used to set the Nth Edge Burst trigger level. If a

digital channel is selected as the source, the :DIGital<n>:THReshold or

:POD<n>:THReshold command is used to set the Nth Edge Burst trigger level.

Table 138 :TRIGger:EBURst Commands Summary

Command Query Options and Query Returns

:TRIGger:EBURst:COUNt

<count> (see

page 1027)

:TRIGger:EBURst:COUNt

? (see page 1027)

<count> ::= integer in NR1 format

:TRIGger:EBURst:IDLE

<time_value> (see

page 1028)

:TRIGger:EBURst:IDLE?

(see page 1028)

<time_value> ::= time in seconds

in NR3 format

:TRIGger:EBURst:SLOPe

<slope> (see

page 1029)

:TRIGger:EBURst:SLOPe

? (see page 1029)

<slope> ::= {NEGative | POSitive}

:TRIGger:EBURst:SOURc

e <source> (see

page 1030)

:TRIGger:EBURst:SOURc

e? (see page 1030)

<source> ::= {CHANnel<n> |

DIGital<d>}

<n> ::= 1 to (# analog channels)

in NR1 format

<d> ::= 0 to (# digital channels

- 1) in NR1 format
