12 :DEMO Commands
When the education kit is licensed (Option EDU), you can output demonstration
signals on the oscilloscope's Demo 1 and Demo 2 terminals. See "Introduction to
:DEMO Commands" on page 299.
Introduction to
:DEMO Commands
The :DEMO subsystem provides commands to output demonstration signals on
the oscilloscope's Demo 1 and Demo 2 terminals.
Reporting the Setup
Use :DEMO? to query setup information for the DEMO subsystem.
Return Format
The following is a sample response from the :DEMO? query. In this case, the query
was issued following the *RST command.
:DEMO:FUNC SIN;OUTP 0
Table 90 :DEMO Commands Summary
Command Query Options and Query Returns
:DEMO:FUNCtion
<signal> (see
page 300)
:DEMO:FUNCtion? (see
page 303)
<signal> ::= {SINusoid | NOISy |
PHASe | RINGing | SINGle | AM |
CLK | GLITch | BURSt | MSO | RUNT
| TRANsition | RFBurst | SHOLd |
LFSine | FMBurst | ETE | CAN |
LIN | UART | I2C | SPI | I2S |
CANLin | ARINc | FLEXray | MIL |
MIL2 | USB | NMONotonic}
:DEMO:FUNCtion:PHASe:
PHASe <angle> (see
page 304)
:DEMO:FUNCtion:PHASe:
PHASe? (see page 304)
<angle> ::= angle in degrees from
0 to 360 in NR3 format
:DEMO:OUTPut {{0 |
OFF} | {1 | ON}} (see
page 305)
:DEMO:OUTPut? (see
page 305)
{0 | 1}
