:SBUS<n> Commands 29
Keysight InfiniiVision 3000T X-Series Oscilloscopes Programmer's Guide 767
:SBUS<n>:I2S Commands
NOTE
These commands are only valid when the I2S serial decode option (Option SND) has been
licensed.
Table 111 :SBUS<n>:I2S Commands Summary
Command Query Options and Query Returns
:SBUS<n>:I2S:ALIGnmen
t <setting> (see
page 769)
:SBUS<n>:I2S:ALIGnmen
t? (see page 769)
<setting> ::= {I2S | LJ | RJ}
:SBUS<n>:I2S:BASE
<base> (see page 770)
:SBUS<n>:I2S:BASE?
(see page 770)
<base> ::= {DECimal | HEX}
:SBUS<n>:I2S:CLOCk:SL
OPe <slope> (see
page 771)
:SBUS<n>:I2S:CLOCk:SL
OPe? (see page 771)
<slope> ::= {NEGative | POSitive}
:SBUS<n>:I2S:RWIDth
<receiver> (see
page 772)
:SBUS<n>:I2S:RWIDth?
(see page 772)
<receiver> ::= 4-32 in NR1 format
:SBUS<n>:I2S:SOURce:C
LOCk <source> (see
page 773)
:SBUS<n>:I2S:SOURce:C
LOCk? (see page 773)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital<d> } for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:SBUS<n>:I2S:SOURce:D
ATA <source> (see
page 774)
:SBUS<n>:I2S:SOURce:D
ATA? (see page 774)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital<d> } for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:SBUS<n>:I2S:SOURce:W
SELect <source> (see
page 775)
:SBUS<n>:I2S:SOURce:W
SELect? (see page 775)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital<d> } for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
