1164 Keysight InfiniiVision 3000T X-Series Oscilloscopes Programmer's Guide

35 :WGEN<w> Commands

:WGEN<w>:VOLTage:OFFSet

(see page 1276)

Command Syntax

:WGEN<w>:VOLTage:OFFSet <offset>

<w> ::= 1 or 2 in NR1 format

<offset> ::= offset in volts in NR3 format

The :WGEN<w>:VOLTage:OFFSet command specifies the waveform's offset

voltage or the DC level. Use the :WGEN<w>:VOLTage command to specify the

amplitude.

You can also specify the amplitude and offset indirectly using the

:WGEN<w>:VOLTage:HIGH and :WGEN<w>:VOLTage:LOW commands. For

example, an amplitude of 5 V and an offset of 1 V is the same as a high-level

voltage of 4 V and a low-level voltage of -1 V.

Query Syntax

:WGEN<w>:VOLTage:OFFSet?

The :WGEN<w>:VOLTage:OFFSet? query returns the currently specified waveform

offset voltage.

Return Format

<offset> ::= offset in volts in NR3 format

See Also • "Introduction to :WGEN<w> Commands" on page 1128

• ":WGEN<w>:FUNCtion" on page 1137

• ":WGEN<w>:VOLTage" on page 1161

• ":WGEN<w>:VOLTage:HIGH" on page 1162

• ":WGEN<w>:VOLTage:LOW" on page 1163

NOTE

When the amplitude is below 40 mV, the offset is limited to ±500 mV.
