496 Keysight InfiniiVision 3000T X-Series Oscilloscopes Programmer's Guide

22 :MEASure Commands

:MEASure:RISetime

(see page 1276)

Command Syntax

:MEASure: RISetime [<source>]

<source> ::= {CHANnel<n> | FUNCtion<m> | MATH<m> | WMEMory<r>}

<n> ::= 1 to (# analog channels) in NR1 format

<m> ::= 1 to (# math functions) in NR1 format

<r> ::= 1 to (# ref waveforms) in NR1 format

The :MEASure:RISetime command installs a screen measurement and starts a

rise-time measurement. If the optional source parameter is specified, the current

source is modified.

Query Syntax

:MEASure: RISetime? [<source>]

The :MEASure:RISetime? query measures and outputs the rise time of the

displayed rising (positive-going) edge closest to the trigger reference. For

maximum measurement accuracy, set the sweep speed as fast as possible while

leaving the leading edge of the waveform on the display. The rise time is

determined by measuring the time at the lower threshold of the rising edge and

the time at the upper threshold of the rising edge, then calculating the rise time

with the following formula:

rise time = time at upper threshold - time at lower threshold

Return Format

<value> ::= rise time in seconds in NR3 format

See Also • "Introduction to :MEASure Commands" on page 458

• ":MEASure:SOURce" on page 499

• ":MEASure:FALLtime" on page 479

NOTE

This command is not available if the source is FFT (Fast Fourier Transform).
