Keysight Technologies InfiniiVision 3000T X Series User Manual

794 Keysight InfiniiVision 3000T X-Series Oscilloscopes Programmer's Guide
29 :SBUS<n> Commands
:SBUS<n>:IIC:TRIGger[:TYPE]
(see page 1276)
Command Syntax
:SBUS<n>:IIC:TRIGger[:TYPE] <value>
<value> ::= {STARt | STOP | READ7 | READEprom | WRITe7 | WRITe10
| NACKnowledge | ANACk | R7Data2 | W7Data2 | RESTart}
The :SBUS<n>:IIC:TRIGger[:TYPE] command sets the IIC trigger type:
• STARt — Start condition.
• STOP — Stop condition.
• READ7 — 7-bit address frame containing (Start:Address7:Read:Ack:Data). The
value READ is also accepted for READ7.
• R7Data2 — 7-bit address frame containing
(Start:Address7:Read:Ack:Data:Ack:Data2).
• READEprom — EEPROM data read.
• WRITe7 — 7-bit address frame containing (Start:Address7:Write:Ack:Data). The
value WRITe is also accepted for WRITe7.
• W7Data2 — 7-bit address frame containing
(Start:Address7:Write:Ack:Data:Ack:Data2).
• WRITe10 — 10-bit address frame containing (Start:Address
byte1:Write:Ack:Address byte 2:Data).
•NACKnowledge — Missing acknowledge.
• ANACk — Address with no acknowledge.
• RESTart — Another start condition occurs before a stop condition.
Query Syntax
:SBUS<n>:IIC:TRIGger[:TYPE]?
The :SBUS<n>:IIC:TRIGger[:TYPE]? query returns the current IIC trigger type value.
Return Format
<value><NL>
<value> ::= {STAR | STOP | READ7 | READE | WRIT7 | WRIT10 | NACK | ANAC
| R7D2 | W7D2 | REST}
See Also • "Introduction to :TRIGger Commands" on page 1007
• ":TRIGger:MODE" on page 1016
• ":SBUS<n>:IIC:TRIGger:PATTern:ADDRess" on page 790
• ":SBUS<n>:IIC:TRIGger:PATTern:DATA" on page 791
NOTE
The short form of READ7 (READ7), READEprom (READE), WRITe7 (WRIT7), and WRITe10
(WRIT10) do not follow the defined Long Form to Short Form Truncation Rules (see
page 1278).
