Keysight InfiniiVision 3000T X-Series Oscilloscopes
Programmer's Guide
35 :WGEN<w> Commands
When the built-in waveform generator is licensed (Option WGN), you can use it to
output sine, square, ramp, pulse, DC, noise, sine cardinal, exponential rise,
exponential fall, cardiac, and gaussian pulse waveforms. The :WGEN<w>
commands are used to select the waveform function and parameters. See
"Introduction to :WGEN<w> Commands" on page 1128.
Table 150 :WGEN<w> Commands Summary
Command Query Options and Query Returns
:WGEN<w>:ARBitrary:BY
Teorder <order> (see
page 1129)
:WGEN<w>:ARBitrary:BY
Teorder? (see
page 1129)
<order> ::= {MSBFirst | LSBFirst}
<w> ::= 1 or 2 in NR1 format
:WGEN<w>:ARBitrary:DA
TA {<binary> |
<value>, <value> ...}
(see page 1130)
n/a <binary> ::= floating point
values between -1.0 to +1.0 in
IEEE 488.2 binary block format
<value> ::= floating point values
between -1.0 to +1.0 in
comma-separated format
<w> ::= 1 or 2 in NR1 format
n/a :WGEN<w>:ARBitrary:DA
TA:ATTRibute:POINts?
(see page 1131)
<points> ::= number of points in
NR1 format
<w> ::= 1 or 2 in NR1 format
:WGEN<w>:ARBitrary:DA
TA:CLEar (see
page 1132)
n/a <w> ::= 1 or 2 in NR1 format
:WGEN<w>:ARBitrary:DA
TA:DAC {<binary> |
<value>, <value> ...}
(see page 1133)
n/a <binary> ::= decimal 16-bit
integer values between -512 to
+511 in IEEE 488.2 binary block
format
<value> ::= decimal integer
values between -512 to +511 in
comma-separated NR1 format
<w> ::= 1 or 2 in NR1 format
