Keysight InfiniiVision 3000T X-Series Oscilloscopes
Programmer's Guide
25 :POD Commands
Control all oscilloscope functions associated with groups of digital channels. See
"Introduction to :POD<n> Commands" on page 583.
Introduction to
:POD<n>
Commands
<n> ::= {1 | 2}
The POD subsystem commands control the viewing and threshold of groups of
digital channels.
POD1 ::= D0-D7
POD2 ::= D8-D15
Reporting the Setup
Use :POD1? or :POD2? to query setup information for the POD subsystem.
Return Format
Table 103 :POD<n> Commands Summary
Command Query Options and Query Returns
:POD<n>:DISPlay {{0 |
OFF} | {1 | ON}} (see
page 585)
:POD<n>:DISPlay? (see
page 585)
{0 | 1}
<n> ::= 1-2 in NR1 format
:POD<n>:SIZE <value>
(see page 586)
:POD<n>:SIZE? (see
page 586)
<value> ::= {SMALl | MEDium |
LARGe}
:POD<n>:THReshold
<type>[suffix] (see
page 587)
:POD<n>:THReshold?
(see page 587)
<n> ::= 1-2 in NR1 format
<type> ::= {CMOS | ECL | TTL |
<user defined value>}
<user defined value> ::= value in
NR3 format
[suffix] ::= {V | mV | uV }
NOTE
These commands are only valid for the MSO models.
