Keysight Technologies InfiniiVision 3000T X Series User Manual

Keysight InfiniiVision 3000T X-Series Oscilloscopes Programmer's Guide 3
In This Book
This book is your guide to programming the 3000T X-Series oscilloscopes:
The first few chapters describe how to set up and get started:
• Chapter 1, “What's New,” starting on page 33, describes programming
command changes in the latest version of oscilloscope software.
• Chapter 2, “Setting Up,” starting on page 41, describes the steps you must take
before you can program the oscilloscope.
• Chapter 3, “Getting Started,” starting on page 51, gives a general overview of
oscilloscope program structure and shows how to program the oscilloscope
using a few simple examples.
• Chapter 4, “Commands Quick Reference,” starting on page 65, is a brief listing
of the 3000T X-Series oscilloscope commands and syntax.
The next chapters provide reference information on common commands, root level
commands, other subsystem commands, and error messages:
• Chapter 5, “Common (*) Commands,” starting on page 165, describes
commands defined by the IEEE 488.2 standard that are common to all
instruments.
• Chapter 6, “Root (:) Commands,” starting on page 191, describes commands
that reside at the root level of the command tree and control many of the basic
functions of the oscilloscope.
• Chapter 7, “:ACQuire Commands,” starting on page 231, describes commands
for setting the parameters used when acquiring and storing data.
• Chapter 8, “:BUS<n> Commands,” starting on page 245, describes commands
that control all oscilloscope functions associated with the digital channels bus
display.
• Chapter 9, “:CALibrate Commands,” starting on page 255, describes utility
commands for determining the state of the calibration factor protection button.
Table 1 InfiniiVision 3000T X-Series Oscilloscope Models, Bandwidths, Sample Rates
Bandwidth 100 MHz 200 MHz 350 MHz 500 MHz 1GHz
Sample Rate (interleaved,
non-interleaved)
5GSa/s,
2.5 GSa/s
5GSa/s,
2.5 GSa/s
5GSa/s,
2.5 GSa/s
5GSa/s,
2.5 GSa/s
5GSa/s,
2.5 GSa/s
2-Channel + 16 Logic
Channels MSO
MSO-X 3012T MSO-X 3022T MSO-X 3032T MSO-X 3052T MSO-X 3102T
4-Channel + 16 Logic
Channels MSO
MSO-X 3014T MSO-X 3024T MSO-X 3034T MSO-X 3054T MSO-X 3104T
2-Channel DSO DSO-X 3012T DSO-X 3022T DSO-X 3032T DSO-X 3052T DSO-X 3102T
4-Channel DSO DSO-X 3014T DSO-X 3024T DSO-X 3034T DSO-X 3054T DSO-X 3104T

Keysight Technologies InfiniiVision 3000T X Series Specifications

General

Brand	Keysight Technologies
Model	InfiniiVision 3000T X Series
Category	Test Equipment
Language	English
