Root (:) Commands 6

Keysight InfiniiVision 3000T X-Series Oscilloscopes Programmer's Guide 227

:STATus

(see page 1276)

Query Syntax

:STATus? <source>

<source> ::= {CHANnel<n> | FUNCtion<m> | MATH<m> | SBUS{1 | 2}

| WMEMory<r>}

for the DSO models

<source> ::= {CHANnel<n> | DIGital<d> | POD{1 | 2}

| BUS{1 | 2} | FUNCtion<m> | MATH<m> | SBUS{1 | 2}

| WMEMory<r>}

for the MSO models

<n> ::= 1 to (# analog channels) in NR1 format

<d> ::= 0 to (# digital channels - 1) in NR1 format

<m> ::= 1 to (# math functions) in NR1 format

<r> ::= 1 to (# ref waveforms) in NR1 format

The :STATus? query reports whether the channel, function, serial decode bus, or

reference waveform location specified by <source> is displayed.

Return Format

<value> ::= {1 | 0}

See Also • "Introduction to Root (:) Commands" on page 194

• ":BLANk" on page 202

• ":CHANnel<n>:DISPlay" on page 270

• ":DIGital<d>:DISPlay" on page 309

• ":FUNCtion<m>:DISPlay" on page 377

• ":POD<n>:DISPlay" on page 585

• ":SBUS<n>:DISPlay" on page 700

• ":WMEMory<r>:DISPlay" on page 1168

• ":VIEW" on page 230

NOTE

MATH<m> is an alias for FUNCtion<m>.
