29 :SBUS<n> Commands
:SBUS<n>:SPI Commands
NOTE
These commands are only valid when the low-speed IIC and SPI serial decode option (Option
LSS) has been licensed.
Table 116 :SBUS<n>:SPI Commands Summary
Command Query Options and Query Returns
:SBUS<n>:SPI:BITorder
<order> (see page 852)
:SBUS<n>:SPI:BITorder
? (see page 852)
<order> ::= {LSBFirst | MSBFirst}
:SBUS<n>:SPI:CLOCk:SL
OPe <slope> (see
page 853)
:SBUS<n>:SPI:CLOCk:SL
OPe? (see page 853)
<slope> ::= {NEGative | POSitive}
:SBUS<n>:SPI:CLOCk:TI
Meout <time_value>
(see page 854)
:SBUS<n>:SPI:CLOCk:TI
Meout? (see page 854)
<time_value> ::= time in seconds
in NR3 format
:SBUS<n>:SPI:FRAMing
<value> (see page 855)
:SBUS<n>:SPI:FRAMing?
(see page 855)
<value> ::= {CHIPselect |
{NCHipselect | NOTC} | TIMeout}
:SBUS<n>:SPI:SOURce:C
LOCk <source> (see
page 856)
:SBUS<n>:SPI:SOURce:C
LOCk? (see page 856)
<value> ::= {CHANnel<n> |
EXTernal} for the DSO models
<value> ::= {CHANnel<n> |
DIGital<d>} for the MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:SBUS<n>:SPI:SOURce:F
RAMe <source> (see
page 857)
:SBUS<n>:SPI:SOURce:F
RAMe? (see page 857)
<value> ::= {CHANnel<n> |
EXTernal} for the DSO models
<value> ::= {CHANnel<n> |
DIGital<d>} for the MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:SBUS<n>:SPI:SOURce:M
ISO <source> (see
page 858)
:SBUS<n>:SPI:SOURce:M
ISO? (see page 858)
<value> ::= {CHANnel<n> |
EXTernal} for the DSO models
<value> ::= {CHANnel<n> |
DIGital<d>} for the MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
