36 :WMEMory<r> Commands
Control reference waveforms.
Table 151 :WMEMory<r> Commands Summary
Command Query Options and Query Returns
:WMEMory<r>:CLEar
(see page 1167)
n/a <r> ::= 1 to (# ref waveforms) in
NR1 format
:WMEMory<r>:DISPlay
{{0 | OFF} | {1 |
ON}} (see page 1168)
:WMEMory<r>:DISPlay?
(see page 1168)
<r> ::= 1 to (# ref waveforms) in
NR1 format
{0 | 1}
:WMEMory<r>:LABel
<string> (see
page 1169)
:WMEMory<r>:LABel?
(see page 1169)
<r> ::= 1 to (# ref waveforms) in
NR1 format
<string> ::= any series of 10 or
less ASCII characters enclosed in
quotation marks
:WMEMory<r>:SAVE
<source> (see
page 1170)
n/a <r> ::= 1 to (# ref waveforms) in
NR1 format
<source> ::= {CHANnel<n> |
FUNCtion<m> | MATH<m>}
<n> ::= 1 to (# analog channels)
in NR1 format
<m> ::= 1 to (# math functions)
in NR1 format
NOTE: Only ADD or SUBtract math
operations can be saved as
reference waveforms.
:WMEMory<r>:SKEW
<skew> (see page 1171)
:WMEMory<r>:SKEW?
(see page 1171)
<r> ::= 1 to (# ref waveforms) in
NR1 format
<skew> ::= time in seconds in NR3
format
:WMEMory<r>:YOFFset
<offset>[suffix] (see
page 1172)
:WMEMory<r>:YOFFset?
(see page 1172)
<r> ::= 1 to (# ref waveforms) in
NR1 format
<offset> ::= vertical offset
value in NR3 format
[suffix] ::= {V | mV}
