:CALibrate Commands 9

Keysight InfiniiVision 3000T X-Series Oscilloscopes Programmer's Guide 259

:CALibrate:OUTPut

(see page 1276)

Command Syntax

:CALibrate:OUTPut <signal>

<signal> ::= {TRIGgers | MASK | WAVEgen | WGEN1}

Note: WAVE and WGEN1 are equivalent.

The CALibrate:OUTPut command sets the signal that is available on the rear panel

TRIG OUT BNC:

• TRIGgers — pulse when a trigger event occurs.

• MASK — signal from mask test indicating a failure.

• WAVEgen, WGEN1 — waveform generator sync output signal. This signal

depends on the :WGEN<w>:FUNCtion setting:

Query Syntax

:CALibrate:OUTPut?

The :CALibrate:OUTPut query returns the current source of the TRIG OUT BNC

signal.

Return Format

<signal> ::= {TRIG | MASK | WAVE}

See Also • "Introduction to :CALibrate Commands" on page 256

• ":WGEN<w>:FUNCtion" on page 1137

Waveform

Type

Sync Signal Characteristics

SINusoid,

SQUare,

RAMP, PULSe,

SINC,

EXPRise,

EXPFall,

GAUSsian

The Sync signal is a TTL positive pulse that occurs when the waveform rises above

zero volts (or the DC offset value).

DC, NOISe,

CARDiac

N/A
