14 :DISPlay Commands
Control how waveforms, graticule, and text are displayed and written on the
screen. See "Introduction to :DISPlay Commands" on page 316.
Table 92 :DISPlay Commands Summary
Command Query Options and Query Returns
:DISPlay:ANNotation<n
> {{0 | OFF} | {1 |
ON}} (see page 318)
:DISPlay:ANNotation<n
>? (see page 318)
{0 | 1}
<n> ::= an integer from 1 to 4 in
NR1 format.
:DISPlay:ANNotation<n
>:BACKground <mode>
(see page 319)
:DISPlay:ANNotation<n
>:BACKground? (see
page 319)
<mode> ::= {OPAQue | INVerted |
TRANsparent}
<n> ::= an integer from 1 to 4 in
NR1 format.
:DISPlay:ANNotation<n
>:COLor <color> (see
page 320)
:DISPlay:ANNotation<n
>:COLor? (see
page 320)
<color> ::= {CH1 | CH2 | CH3 |
CH4 | DIG | MATH | REF | MARKer |
WHITe | RED}
<n> ::= an integer from 1 to 4 in
NR1 format.
:DISPlay:ANNotation<n
>:TEXT <string> (see
page 321)
:DISPlay:ANNotation<n
>:TEXT? (see page 321)
<string> ::= quoted ASCII string
(up to 254 characters)
<n> ::= an integer from 1 to 4 in
NR1 format.
:DISPlay:ANNotation<n
>:X1Position <value>
(see page 322)
:DISPlay:ANNotation<n
>:X1Position? (see
page 322)
<value> ::= an integer from 0 to
(800 - width of annotation) in
NR1 format.
<n> ::= an integer from 1 to 4 in
NR1 format.
:DISPlay:ANNotation<n
>:Y1Position <value>
(see page 323)
:DISPlay:ANNotation<n
>:Y1Position? (see
page 323)
<value> ::= an integer from 0 to
(480 - height of annotation) in
NR1 format.
<n> ::= an integer from 1 to 4 in
NR1 format.
:DISPlay:CLEar (see
page 324)
n/a n/a
