Keysight InfiniiVision 3000T X-Series Oscilloscopes
Programmer's Guide
29 :SBUS<n> Commands
Control the modes and parameters for each serial bus decode/trigger type. See:
• "Introduction to :SBUS<n> Commands" on page 697
• "General :SBUS<n> Commands" on page 699
• ":SBUS<n>:A429 Commands" on page 702
• ":SBUS<n>:CAN Commands" on page 719
• ":SBUS<n>:FLEXray Commands" on page 748
• ":SBUS<n>:I2S Commands" on page 767
• ":SBUS<n>:IIC Commands" on page 786
• ":SBUS<n>:LIN Commands" on page 796
• ":SBUS<n>:M1553 Commands" on page 810
• ":SBUS<n>:SENT Commands" on page 817
• ":SBUS<n>:SPI Commands" on page 850
• ":SBUS<n>:UART Commands" on page 866
Introduction to
:SBUS<n>
Commands
The :SBUS subsystem commands control the serial decode bus viewing, mode,
and other options.
The following serial bus decode/trigger types are available (see ":TRIGger:MODE"
on page 1016).
• CAN (Controller Area Network) triggering— will trigger on CAN version 2.0A
and 2.0B signals. Setup consists of connecting the oscilloscope to a CAN
signal. Baud rate, signal source, and signal polarity, and type of data to trigger
on can be specified. You can trigger on CAN data and identifier patterns and
you can set the bit sample point.
• I2S (Inter-IC Sound or Integrated Interchip Sound bus) triggering— consists of
connecting the oscilloscope to the serial clock, word select, and serial data
lines, then triggering on a data value.
NOTE
These commands are only valid on oscilloscope models when a serial decode option has been
licensed.
