Status Reporting 39
Keysight InfiniiVision 3000T X-Series Oscilloscopes Programmer's Guide 1255
Operation Status Event Register (:OPERegister[:EVENt])
The Operation Status Event Register register hosts these bits:
If any of these bits are set, the OPER bit (bit 7) of the Status Byte Register is set.
The Operation Status Event Register is read and cleared with the
:OPERegister[:EVENt]? query. The register output is enabled or disabled using the
mask value supplied with the OPEE command.
Name Location Description
RUN bit bit 3 Is set whenever the instrument goes from a stop state
to a single or running state.
WAIT TRIG bit bit 5 Is set by the Trigger Armed Event Register and
indicates that the trigger is armed.
MTE bit bit 9 Comes from the Mask Test Event Registers.
OVLR bit bit 11 Is set whenever a 50Ω input overload occurs.
HWE bit bit 12 Comes from the Hardware Event Registers.
IOC bit bit 13 Is set when the IO operation completes.
IOF bit bit 14 Is set when the IO operation fails.
