1032 Keysight InfiniiVision 3000T X-Series Oscilloscopes Programmer's Guide

33 :TRIGger Commands

:TRIGger[:EDGE]:COUPling

(see page 1276)

Command Syntax

:TRIGger[:EDGE]:COUPling <coupling>

<coupling> ::= {AC | DC | LFReject}

The :TRIGger[:EDGE]:COUPling command sets the input coupling for the selected

trigger sources. The coupling can be set to AC, DC, or LFReject.

• AC coupling places a high-pass filter (10 Hz for analog channels, and 3.5 Hz for

all External trigger inputs) in the trigger path, removing dc offset voltage from

the trigger waveform. Use AC coupling to get a stable edge trigger when your

waveform has a large dc offset.

• LFReject coupling places a 50 KHz high-pass filter in the trigger path.

• DC coupling allows dc and ac signals into the trigger path.

Query Syntax

:TRIGger[:EDGE]:COUPling?

The :TRIGger[:EDGE]:COUPling? query returns the current coupling selection.

Return Format

<coupling> ::= {AC | DC | LFR}

See Also • "Introduction to :TRIGger Commands" on page 1007

• ":TRIGger:MODE" on page 1016

• ":TRIGger[:EDGE]:REJect" on page 1034

NOTE

The :TRIGger[:EDGE]:COUPling and the :TRIGger[:EDGE]:REJect selections are coupled.

Changing the setting of the :TRIGger[:EDGE]:REJect can change the COUPling setting.
