:MEASure:DEFine

(see page 1276)

Command Syntax

:MEASure:DEFine <meas_spec>[,<source>]

<meas_spec> ::= {DELay | THResholds}

<source> ::= {CHANnel<n> | FUNCtion<m> | MATH<m> | WMEMory<r>}

<n> ::= 1 to (# analog channels) in NR1 format

<m> ::= 1 to (# math functions) in NR1 format

<r> ::= 1 to (# ref waveforms) in NR1 format

The :MEASure:DEFine command sets up the definition for measurements by

specifying the delta time or threshold values. Changing these values may affect

the results of other measure commands. The table below identifies which

measurement results that can be affected by redefining the DELay specification or

the THResholds values. For example, changing the THResholds definition from the

default 10%, 50%, and 90% values may change the returned measurement result.

:MEASure:DEFine

DELay Command

Syntax

:MEASure:DEFine DELay,<delay spec>[,<source>]

<edge_spec1> ::= [<slope>]<occurrence>

<edge_spec2> ::= [<slope>]<occurrence>

MEASure Command DELay THResholds

DUTYcycle x

DELay x x

FALLtime x

FREQuency x

NWIDth x

OVERshoot x

PERiod x

PHASe x

PREShoot x

PWIDth x

RISetime x

VAVerage x

VRMS x
