:POD<n>:THReshold

(see page 1276)

Command Syntax

:POD<n>:THReshold <type>[<suffix>]

<n> ::= An integer, 1 or 2, is attached as a suffix to the command and

defines the group of channels that are affected by the command.

<type> ::= {CMOS | ECL | TTL | <user defined value>}

<user defined value> ::= -8.00 to +8.00 in NR3 format

<suffix> ::= {V | mV | uV}

POD1 ::= D0-D7

POD2 ::= D8-D15

TTL ::= 1.4V

CMOS ::= 2.5V

ECL ::= -1.3V

The :POD<n>:THReshold command sets the threshold for the specified group of

channels. The threshold is used for triggering purposes and for displaying the

digital data as high (above the threshold) or low (below the threshold).

Query Syntax

:POD<n>:THReshold?

The :POD<n>:THReshold? query returns the threshold value for the specified group

of channels.

Return Format

<threshold> ::= Floating point number in NR3 format

See Also • "Introduction to :POD<n> Commands" on page 583

• ":DIGital<d>:THReshold" on page 313

• ":TRIGger[:EDGE]:LEVel" on page 1033

Example Code

' THRESHOLD - This command is used to set the voltage threshold for

' the waveforms. There are three preset values (TTL, CMOS, and ECL)

' and you can also set a user-defined threshold value between

' -8.0 volts and +8.0 volts.

' In this example, we set channels 0-7 to CMOS, then set channels

' 8-15 to a user-defined 2.0 volts, and then set the external trigger

' to TTL. Of course, you only need to set the thresholds for the

' channels you will be using in your program.

NOTE

This command is only valid for the MSO models.
