1256 Keysight InfiniiVision 3000T X-Series Oscilloscopes Programmer's Guide
39 Status Reporting
Operation Status Condition Register (:OPERegister:CONDition)
The Operation Status Condition Register register hosts these bits:
The :OPERegister:CONDition? query returns the value of the Operation Status
Condition Register.
Name Location Description
RUN bit bit 3 Is set whenever the instrument is not stopped.
WAIT TRIG bit bit 5 Is set by the Trigger Armed Event Register and
indicates that the trigger is armed.
MTE bit bit 9 Comes from the Mask Test Event Registers.
OVLR bit bit 11 Is set whenever a 50Ω input overload occurs.
HWE bit bit 12 Comes from the Hardware Event Registers.
IOC bit bit 13 Is set when the IO operation completes.
IOF bit bit 14 Is set when the IO operation fails.
