810 Keysight InfiniiVision 3000T X-Series Oscilloscopes Programmer's Guide
29 :SBUS<n> Commands
:SBUS<n>:M1553 Commands
NOTE
These commands are valid when the DSOX4AERO MIL-STD-1553 and ARINC 429 triggering
and serial decode option (Option AERO) has been licensed.
Table 114 :SBUS<n>:M1553 Commands Summary
Command Query Options and Query Returns
:SBUS<n>:M1553:AUTose
tup (see page 811)
n/a n/a
:SBUS<n>:M1553:BASE
<base> (see page 812)
:SBUS<n>:M1553:BASE?
(see page 812)
<base> ::= {BINary | HEX}
:SBUS<n>:M1553:SOURce
<source> (see
page 813)
:SBUS<n>:M1553:SOURce
? (see page 813)
<source> ::= {CHANnel<n>}
<n> ::= 1 to (# analog channels)
in NR1 format
:SBUS<n>:M1553:TRIGge
r:PATTern:DATA
<string> (see
page 814)
:SBUS<n>:M1553:TRIGge
r:PATTern:DATA? (see
page 814)
<string> ::= "nn...n" where n ::=
{0 | 1 | X}
:SBUS<n>:M1553:TRIGge
r:RTA <value> (see
page 815)
:SBUS<n>:M1553:TRIGge
r:RTA? (see page 815)
<value> ::= 5-bit integer in
decimal, <nondecimal>, or
<string> from 0-31
<nondecimal> ::= #Hnn where n ::=
{0,..,9|A,..,F}
<string> ::= "0xnn" where n::=
{0,..,9|A,..,F}
:SBUS<n>:M1553:TRIGge
r:TYPE <type> (see
page 816)
:SBUS<n>:M1553:TRIGge
r:TYPE? (see page 816)
<type> ::= {DSTArt | DSTOp |
CSTArt | CSTOp | RTA | PERRor |
SERRor | MERRor | RTA11}
