438 Keysight InfiniiVision 3000T X-Series Oscilloscopes Programmer's Guide

21 :MARKer Commands

:MARKer:Y2Position

(see page 1276)

Command Syntax

:MARKer:Y2Position <position> [suffix]

<position> ::= Y2 cursor position in NR3 format

<suffix> ::= {mV | V | dB}

If the :MARKer:MODE is not currently set to WAVeform (see ":MARKer:MODE" on

page 429), the :MARKer:Y1Position command:

•Sets :MARKer:MODE to MANual.

• Sets the Y2 cursor position to the specified value.

Y cursor units are set by the :MARKer:YUNits command.

When the :MARKer:MODE is set to WAVeform, Y positions cannot be set.

Query Syntax

:MARKer:Y2Position?

The :MARKer:Y2Position? query returns current Y2 cursor position. This is

functionally equivalent to the obsolete :MEASure:VSTOp command/query.

Return Format

<position> ::= Y2 cursor position in NR3 format

See Also • "Introduction to :MARKer Commands" on page 426

• ":MARKer:MODE" on page 429

• ":MARKer:X1Y1source" on page 431

• ":MARKer:X2Y2source" on page 433

• ":MARKer:Y1Position" on page 437

• ":MARKer:YUNits" on page 440

• ":MEASure:VSTOp" on page 1214

NOTE

If the front-panel cursors are off or are set to Binary or Hex Mode, the marker position values

are not defined and an error is generated. Make sure to set :MARKer:MODE to MANual or

WAVeform to put the cursors in the front-panel Normal mode.
