Keysight InfiniiVision 3000T X-Series Oscilloscopes
Programmer's Guide
24 :MTESt Commands
The MTESt subsystem commands and queries control the mask test features. See
"Introduction to :MTESt Commands" on page 551.
Table 102 :MTESt Commands Summary
Command Query Options and Query Returns
:MTESt:ALL {{0 | OFF}
| {1 | ON}} (see
page 554)
:MTESt:ALL? (see
page 554)
{0 | 1}
:MTESt:AMASk:CREate
(see page 555)
n/a n/a
:MTESt:AMASk:SOURce
<source> (see
page 556)
:MTESt:AMASk:SOURce?
(see page 556)
<source> ::= CHANnel<n>
<n> ::= {1 | 2 | 3 | 4} for 4ch
models
<n> ::= {1 | 2} for 2ch models
:MTESt:AMASk:UNITs
<units> (see page 557)
:MTESt:AMASk:UNITs?
(see page 557)
<units> ::= {CURRent | DIVisions}
:MTESt:AMASk:XDELta
<value> (see page 558)
:MTESt:AMASk:XDELta?
(see page 558)
<value> ::= X delta value in NR3
format
:MTESt:AMASk:YDELta
<value> (see page 559)
:MTESt:AMASk:YDELta?
(see page 559)
<value> ::= Y delta value in NR3
format
n/a :MTESt:COUNt:FWAVefor
ms? [CHANnel<n>] (see
page 560)
<failed> ::= number of failed
waveforms in NR1 format
:MTESt:COUNt:RESet
(see page 561)
n/a n/a
n/a :MTESt:COUNt:TIME?
(see page 562)
<time> ::= elapsed seconds in NR3
format
n/a :MTESt:COUNt:WAVeform
s? (see page 563)
<count> ::= number of waveforms
in NR1 format
:MTESt:DATA <mask>
(see page 564)
:MTESt:DATA? (see
page 564)
<mask> ::= data in IEEE 488.2 #
format.
