:MTESt Commands 24
Keysight InfiniiVision 3000T X-Series Oscilloscopes Programmer's Guide 551
Introduction to
:MTESt Commands
Mask testing automatically compares the current displayed waveform with the
boundaries of a set of polygons that you define. Any waveform or sample that falls
within the boundaries of one or more polygons is recorded as a failure.
Reporting the Setup
Use :MTESt? to query setup information for the MTESt subsystem.
Return Format
The following is a sample response from the :MTESt? query. In this case, the query
was issued following a *RST command.
:MTES:SOUR CHAN1;ENAB 0;LOCK 1;:MTES:AMAS:SOUR CHAN1;UNIT DIV;XDEL
+2.50000000E-001;YDEL +2.50000000E-001;:MTES:SCAL:X1 +200.000E-06;XDEL
+400.000E-06;Y1 -3.00000E+00;Y2 +3.00000E+00;BIND 0;:MTES:RMOD
FOR;RMOD:TIME +1E+00;WAV 1000;SIGM +6.0E+00;:MTES:RMOD:FACT:STOP
0;PRIN 0;SAVE 0
Example Code
' Mask testing commands example.
' -------------------------------------------------------------------
Option Explicit
Public myMgr As VisaComLib.ResourceManager
Public myScope As VisaComLib.FormattedIO488
Public varQueryResult As Variant
Public strQueryResult As String
Private Declare Sub Sleep Lib "kernel32" (ByVal dwMilliseconds As Long)
Sub Main()
:MTESt:SCALe:Y1
<y1_value> (see
page 579)
:MTESt:SCALe:Y1? (see
page 579)
<y1_value> ::= Y1 value in NR3
format
:MTESt:SCALe:Y2
<y2_value> (see
page 580)
:MTESt:SCALe:Y2? (see
page 580)
<y2_value> ::= Y2 value in NR3
format
:MTESt:SOURce
<source> (see
page 581)
:MTESt:SOURce? (see
page 581)
<source> ::= {CHANnel<n> | NONE}
<n> ::= {1 | 2 | 3 | 4} for 4ch
models
<n> ::= {1 | 2} for 2ch models
n/a :MTESt:TITLe? (see
page 582)
<title> ::= a string of up to 128
ASCII characters
Table 102 :MTESt Commands Summary (continued)
Command Query Options and Query Returns
