:SEARch Commands 30

Keysight InfiniiVision 3000T X-Series Oscilloscopes Programmer's Guide 895

:SEARch:EDGE Commands

Table 119 :SEARch:EDGE Commands Summary

Command Query Options and Query Returns

:SEARch:EDGE:SLOPe

<slope> (see page 896)

:SEARch:EDGE:SLOPe?

(see page 896)

<slope> ::= {POSitive | NEGative

| EITHer}

:SEARch:EDGE:SOURce

<source> (see

page 897)

:SEARch:EDGE:SOURce?

(see page 897)

<source> ::= CHANnel<n>

<n> ::= 1 to (# analog channels)

in NR1 format
