Keysight Technologies InfiniiVision 3000T X Series - :SBUS<n>:LIN Commands

796 Keysight InfiniiVision 3000T X-Series Oscilloscopes Programmer's Guide
29 :SBUS<n> Commands
:SBUS<n>:LIN Commands
NOTE
These commands are valid when the automotive CAN and LIN serial decode option (Option
AMS) has been licensed.
Table 113 :SBUS<n>:LIN Commands Summary
Command Query Options and Query Returns
:SBUS<n>:LIN:PARity
{{0 | OFF} | {1 |
ON}} (see page 798)
:SBUS<n>:LIN:PARity?
(see page 798)
{0 | 1}
:SBUS<n>:LIN:SAMPlepo
int <value> (see
page 799)
:SBUS<n>:LIN:SAMPlepo
int? (see page 799)
<value> ::= {60 | 62.5 | 68 | 70
| 75 | 80 | 87.5} in NR3 format
:SBUS<n>:LIN:SIGNal:B
AUDrate <baudrate>
(see page 800)
:SBUS<n>:LIN:SIGNal:B
AUDrate? (see
page 800)
<baudrate> ::= integer from 2400
to 625000 in 100 b/s increments
:SBUS<n>:LIN:SOURce
<source> (see
page 801)
:SBUS<n>:LIN:SOURce?
(see page 801)
<source> ::= {CHANnel<n> |
EXTernal} for DSO models
<source> ::= {CHANnel<n> |
DIGital<d>} for MSO models
<n> ::= 1 to (# analog channels)
in NR1 format
<d> ::= 0 to (# digital channels
- 1) in NR1 format
:SBUS<n>:LIN:STANdard
<std> (see page 802)
:SBUS<n>:LIN:STANdard
? (see page 802)
<std> ::= {LIN13 | LIN20}
:SBUS<n>:LIN:SYNCbrea
k <value> (see
page 803)
:SBUS<n>:LIN:SYNCbrea
k? (see page 803)
<value> ::= integer = {11 | 12 |
13}
:SBUS<n>:LIN:TRIGger
<condition> (see
page 804)
:SBUS<n>:LIN:TRIGger?
(see page 804)
<condition> ::= {SYNCbreak | ID |
DATA}
:SBUS<n>:LIN:TRIGger:
ID <value> (see
page 805)
:SBUS<n>:LIN:TRIGger:
ID? (see page 805)
<value> ::= 7-bit integer in
decimal, <nondecimal>, or
<string> from 0-63 or 0x00-0x3f
<nondecimal> ::= #Hnn where n ::=
{0,..,9 | A,..,F} for hexadecimal
<nondecimal> ::= #Bnn...n where n
::= {0 | 1} for binary
<string> ::= "0xnn" where n ::=
{0,..,9 | A,..,F} for hexadecimal
